Current - Collector (Ic) (Max):
8 A
RoHS Status:
ROHS3 Compliant
Switching Energy:
68µJ (on), 45µJ (off)
Vce(on) (Max) @ Vge, Ic:
1.95V @ 15V, 3A
Voltage - Collector Emitter Breakdown (Max):
600 V
Td (on/off) @ 25°C:
35ns/121ns
Operating Temperature:
-55°C ~ 175°C (TJ)
Input Type:
Standard
Package / Case:
TO-252-3, DPAK (2 Leads + Tab), SC-63
Gate Charge:
35 nC
Reverse Recovery Time (trr):
73 ns
REACH Status:
REACH Affected
Test Condition:
400V, 3A, 47Ohm, 15V
Package:
Tape & Reel (TR)
Moisture Sensitivity Level (MSL):
1 (Unlimited)
standardLeadTime:
18 Weeks
IGBT Type:
Trench Field Stop
Current - Collector Pulsed (Icm):
16 A
Mounting Type:
Surface Mount
Series:
H
Supplier Device Package:
DPAK (TO-252) type C2
Power - Max:
75 W
Mounting Type:
Surface Mount
Maximum Power Dissipation:
75 W
Maximum Collector Emitter Voltage:
600 V
Number of Transistors:
1
Maximum Continuous Collector Current:
4 A
Maximum Gate Emitter Voltage:
±20V
Package Type:
DPAK
Configuration:
Single Collector, Single Emitter, Single Gate
Pin Count:
3
