STMicroelectronics STGP3HF60HD
Product Information
Dimensions:
10.4 x 4.6 x 15.75mm
Mounting Type:
Through Hole
Maximum Power Dissipation:
38 W
Maximum Collector Emitter Voltage:
600 V
Channel Type:
N
Maximum Continuous Collector Current:
7.5 A
Maximum Gate Emitter Voltage:
±20V
Package Type:
TO-220
Minimum Operating Temperature:
-55 °C
Maximum Operating Temperature:
+150 °C
Pin Count:
3
Transistor Configuration:
Single
Current - Collector (Ic) (Max):
7.5 A
Reverse Recovery Time (trr):
85 ns
HTSUS:
8541.29.0095
RoHS Status:
ROHS3 Compliant
Switching Energy:
19µJ (on), 12µJ (off)
Vce(on) (Max) @ Vge, Ic:
2.95V @ 15V, 1.5A
Voltage - Collector Emitter Breakdown (Max):
600 V
Td (on/off) @ 25°C:
11ns/60ns
Operating Temperature:
-55°C ~ 150°C (TJ)
Input Type:
Standard
Package / Case:
TO-220-3
Gate Charge:
12 nC
REACH Status:
REACH Unaffected
edacadModel:
STGP3HF60HD Models
edacadModelUrl:
/en/models/5308112
Test Condition:
400V, 1.5A, 100Ohm, 15V
Package:
Tube
Moisture Sensitivity Level (MSL):
1 (Unlimited)
standardLeadTime:
12 Weeks
IGBT Type:
-
Current - Collector Pulsed (Icm):
18 A
Mounting Type:
Through Hole
Series:
-
Supplier Device Package:
TO-220
Power - Max:
38 W
Base Product Number:
STGP3
ECCN:
EAR99
