Mount Type:
Flush
Width:
48 mm
Actuator Style:
Octagonal
Contact DC Voltage:
125V dc
Illuminated:
No
Product Type:
Push Button Switch
Maximum Operating Temperature:
70°C
Terminal Type:
Screw
IP Rating:
IP66
Contact AC Voltage:
240V ac
Contact Configuration:
SPDT
Panel Cutout Size:
30 mm
Length:
56mm
Standards/Approvals:
WEEE, EU RoHS, RoHS, REACH
LED Colour:
White, Blue, Orange, Yellow, Black, Green, Red
Switch Operation:
Momentary
Series:
Harmony 9001K
Height:
45mm
Minimum Operating Temperature:
-25°C
Switch Contact Current:
3 A
HTSUS:
8536.50.9031
RoHS Status:
ROHS3 Compliant
Electrical Life:
-
Termination Style:
Screw Terminal
Voltage Rating - DC:
125 V
Operating Temperature:
-25°C ~ 70°C
Panel Cutout Dimensions:
Circular - 30.00mm Dia
Mechanical Life:
5,000,000 Cycles
Type:
Standard
Color - Actuator/Cap:
-
title:
9001KR1UH13
Voltage Rating - AC:
240 V
REACH Status:
REACH Affected
Illumination Type, Color:
-
Switch Function:
On-On
Moisture Sensitivity Level (MSL):
Not Applicable
Circuit:
SPDT
standardLeadTime:
5 Weeks
Current Rating (Amps):
3A (AC), 550mA (DC)
Ingress Protection:
IP66 - Dust Tight, Water Resistant
Features:
-
Mounting Type:
Panel Mount, Front
Series:
Harmony 9001K
Packaging:
Box
Actuator Type:
Round, Button, Flush
Illumination Voltage (Nominal):
-
ECCN:
EAR99
