Maximum Continuous Drain Current:
P Channel) A, 4 (N Channel
Width:
2.1mm
Maximum Drain Source Voltage:
30 V
Maximum Gate Threshold Voltage:
2.5 (N Channel) V, 2.5 (P Channel) V
Maximum Drain Source Resistance:
103 mΩ
Package Type:
DFN2020, HUML2020L
Number of Elements per Chip:
2
Minimum Gate Threshold Voltage:
1 (N Channel) V, 1 (P Channel) V
Maximum Operating Temperature:
+150 °C
Typical Gate Charge @ Vgs:
4.3 nC @ 10 V (N Channel), 6.7 nC @ 10 V (P Channel)
Channel Type:
N, P
Length:
2.1mm
Pin Count:
8
Channel Mode:
Enhancement
Mounting Type:
Surface Mount
Maximum Power Dissipation:
2 W
Series:
UT6MA2
Maximum Gate Source Voltage:
P Channel) V, ±20 (N Channel
Height:
0.6mm
Minimum Operating Temperature:
-55 °C
