HTSUS:
8542.31.0001
RoHS Status:
ROHS3 Compliant
Program Memory Size:
4MB (4M x 8)
Peripherals:
Brown-out Detect/Reset, Crypto - AES, DMA, LCD, PWM, SHA, Temp Sensor, TRNG, WDT
Operating Temperature:
-40°C ~ 85°C (TA)
Voltage - Supply (Vcc/Vdd):
1.71V ~ 3.6V
Package / Case:
144-LQFP
RAM Size:
2.5M x 8
Packaging:
Tray
Program Memory Type:
FLASH
Connectivity:
CANbus, EBI/EMI, FIFO, I2C, IrDA, LINbus, MMC/SD, SPI, UART/USART/USB
EEPROM Size:
-
Oscillator Type:
External, Internal
Moisture Sensitivity Level (MSL):
3 (168 Hours)
Number of I/O:
111
standardLeadTime:
10 Weeks
Core Size:
32-Bit
Mounting Type:
Surface Mount
Series:
STM32U5
Supplier Device Package:
144-LQFP (20x20)
Data Converters:
A/D 22x12/14b SAR; D/A 2x12b
Core Processor:
ARM® Cortex®-M33
Speed:
160MHz
Base Product Number:
STM32U5A9
ECCN:
5A992C
Program Memory Size:
4MB
DACs:
1 x 12 Bit
Automotive Standard:
No
Number of Timers:
19
RAM Size:
2.5MB
Data Bus Width:
32bit
Instruction Set Architecture:
ARM V8-M
Program Memory Type:
FLASH
Minimum Supply Voltage:
1.71V
Package Type:
LQFP
Analogue Comparators:
2
Maximum Clock Frequency:
160MHz
Product Type:
Microcontroller
Maximum Operating Temperature:
125°C
Device Core:
ARM Cortex M33
Standards/Approvals:
PSA Level 3, SESIP3, ECOPACK2
Pin Count:
144
Mount Type:
Surface
Number of Programmable I/Os:
156
Series:
STM32U5Axxx
Maximum Supply Voltage:
3.6V
ADCs:
1 x 12 Bit, 2 x 14 Bit
Minimum Operating Temperature:
-40°C
