HTSUS:
8542.31.0001
RoHS Status:
ROHS3 Compliant
Program Memory Size:
1MB (1M x 8)
Peripherals:
DMA, Motor Control PWM, PDR, POR, PVD, PWM, Temp Sensor, WDT
Operating Temperature:
-40°C ~ 85°C (TA)
Voltage - Supply (Vcc/Vdd):
2V ~ 3.6V
Package / Case:
100-LQFP
RAM Size:
96K x 8
Data Converters:
A/D 16x12b; D/A 2x12b
Program Memory Type:
FLASH
REACH Status:
REACH Unaffected
edacadModel:
STM32F103VGT6TR Models
Connectivity:
CANbus, I2C, IrDA, LINbus, SPI, UART/USART, USB
edacadModelUrl:
/en/models/5268223
EEPROM Size:
-
Oscillator Type:
Internal
Moisture Sensitivity Level (MSL):
3 (168 Hours)
Number of I/O:
80
standardLeadTime:
10 Weeks
DigiKey Programmable:
Not Verified
Core Size:
32-Bit Single-Core
Mounting Type:
Surface Mount
Series:
STM32F1
Supplier Device Package:
100-LQFP (14x14)
Packaging:
Tape & Reel (TR)
Core Processor:
ARM® Cortex®-M3
Speed:
72MHz
Base Product Number:
STM32F103
ECCN:
3A991A2
Number of Timers:
17
Data Bus Width:
32bit
Maximum Supply Voltage:
3.6V
Number of Programmable I/Os:
112
Program Memory Type:
FLASH
Maximum Clock Frequency:
72MHz
Automotive Standard:
No
Device Core:
ARM Cortex M3
Minimum Supply Voltage:
2V
Package Type:
LQFP
Minimum Operating Temperature:
-40°C
Program Memory Size:
1MB
Standards/Approvals:
RoHS
Product Type:
32 Bit Microcontroller
Maximum Operating Temperature:
125°C
Pin Count:
100
Mount Type:
Surface
