This is Quad 2-Input NAND Logic Gate 2 → 6 V 14-Pin SOP manufactured by Toshiba. The manufacturer part number is TC74HC00AF(F). On the other hand, it is featured with 5.2ma of max. low level output current. While a -5.2ma of maximum high level output current. The given dimensions of the product include 10.3 x 5.3 x 1.5mm. The product is available in surface mount configuration. It contains 2 inputs per gate . While its minimum operating supply voltage is 2 v. The primary function of logic includes nand. The logic family is hc. In addition, the height is 1.5mm. Furthermore, the product is 5.3mm wide. Its accurate length is 10.3mm. The package is a sort of sop. Features 50pf of propagation delay test condition. Whereas, the minimum operating temperature of the product is -40 °c. It provides up to 13 ns @ 6 v, 15 ns @ 4.5 v, 75 ns @ 2 v maximum propagation delay time. Schmitt Trigger Input - no. It carries 4 elements. It has a maximum operating temperature of +85 °c. It contains 14 pins. It has 6 v maximum operating supply voltage.
For more information please check the datasheets.
