Logic Gates Logic Gates QUAD 2-INPUT OR

74LVC32AD-112 Logic Gates Logic Gates QUAD 2-INPUT OR
74LVC32AD-112 Logic Gates Logic Gates QUAD 2-INPUT OR
Nexperia

Product Information

Logic Family:
74LVC
Width:
4 mm
Input Type:
CMOS, TTL
Height:
1.45mm
Automotive Standard:
No
Maximum Low Level Output Current:
24mA
Maximum High Level Output Current:
-24mA
Output Type:
CMOS
Minimum Supply Voltage:
1.65V
Package Type:
SO
Product Type:
Logic Gate
Maximum Operating Temperature:
125°C
Number of Inputs per Gate:
2
Length:
8.75mm
Standards/Approvals:
JESD8-5A, JEDEC JESD8-7A, JESD8-C/JESD36
Pin Count:
14
Mount Type:
Surface
Maximum Propagation Delay Time @ CL:
5ns
Series:
74LVC
Logic Function:
OR
Maximum Supply Voltage:
3.6V
Minimum Operating Temperature:
-40°C
Schmitt Trigger Input:
Yes
Number of Elements:
4
RoHs Compliant
Checking for live stock

This is Logic Gates Logic Gates QUAD 2-INPUT OR manufactured by Nexperia. The manufacturer part number is 74LVC32AD,112. The logic family is 74lvc. Furthermore, the product is 4 mm wide. It carries cmos, ttl input type. In addition, the height is 1.45mm. The product complies with automotive standard - no. On the other hand, it is featured with 24ma of max. low level output current. While a -24ma of maximum high level output current. Furthermore, it has acmos output. It has a minimum 1.65v supply voltage . The package is a sort of so. logic gate is a versatile product designed to provide user-defined applications. It has a maximum operating temperature of 125°c. It contains 2 inputs per gate . Its accurate length is 8.75mm. It contains 14 pins. It has a surface type mount . The product 74lvc, is a highly preferred choice for users. The primary function of logic includes or. The product requires a maximum 3.6v supply voltage . Whereas, the minimum operating temperature of the product is -40°c. Schmitt Trigger Input - yes. It carries 4 elements.

pdf icon
Datasheet 74LVC32AD,112(Technical Reference)
