This is 2-Input AND Logic Gate 5-Pin TSSOP manufactured by Nexperia. The manufacturer part number is 74HC1G08GW,125. The given dimensions of the product include 2.25 x 1.35 x 1mm. The logic family is hc. Furthermore, the product is 1.35mm wide. It carries cmos input type. On the other hand, it is featured with 2.6ma of max. low level output current. While a -2.6ma of maximum high level output current. It provides up to 135ns maximum propagation delay time. While its minimum operating supply voltage is 2 v. Furthermore, it has acurrent output. The package is a sort of tssop. It has a maximum operating temperature of +125 °c. It contains 2 inputs per gate . Its accurate length is 2.25mm. It contains 5 pins. It has 6 v maximum operating supply voltage. The product is available in surface mount configuration. The primary function of logic includes and. In addition, the height is 1mm. Whereas, the minimum operating temperature of the product is -40 °c. Schmitt Trigger Input - no. It carries 1 elements. Features 50pf of propagation delay test condition.
74HC1G08 74HCT1G08 2-input AND gate Data Sheet(Technical Reference)
ESD Control Selection Guide V1(Technical Reference)
