ROHM BA12003BF-E2, 7-element NPN Darlington Pair, 500 mA 60 V HFE:1000, 16-Pin SOP
Product Information
Maximum Continuous Collector Current:
500 mA
Minimum DC Current Gain:
1000
Transistor Type:
NPN
Dimensions:
10 x 4.4 x 1.5mm
Mounting Type:
Surface Mount
Maximum Power Dissipation:
620 mW
Maximum Operating Temperature:
+85 °C
Maximum Collector Emitter Voltage:
60 V
Height:
1.5mm
Width:
4.4mm
Length:
10mm
Package Type:
SOP
Number of Elements per Chip:
7
Minimum Operating Temperature:
-40 °C
Maximum Collector Emitter Saturation Voltage:
1.6 V
Configuration:
Array 7
Base Current:
1.35mA
Pin Count:
16
Transistor Configuration:
Common Emitter
Checking for live stock
FAQs
Yes. You can also search BA12003BF-E2 on website for other similar products.
We accept all major payment methods for all products including ET16780813. Please check your shopping cart at the time of order.
You can order ROHM brand products with BA12003BF-E2 directly through our website or call us at +44 (0) 3303 800 157 or email our support team at sales@enrgtech.co.uk.
Yes. Our products in Darlington Pairs category are shipped in lowest possible time.
You will get a confirmation email regarding your order of ROHM BA12003BF-E2, 7-element NPN Darlington Pair, 500 mA 60 V HFE:1000, 16-Pin SOP. You can also check on our website or by contacting our customer support team for further order details on ROHM BA12003BF-E2, 7-element NPN Darlington Pair, 500 mA 60 V HFE:1000, 16-Pin SOP.
We use our internationally recognized delivery partners UPS/DHL. Collection of ET16780813 can also be arranged for the customer by international shipments through contacting our customer support team. Additionally, you can also search "ROHM" products on our website by using Enrgtech's Unique Manufacturing Part Number ET16780813.
Yes. We ship BA12003BF-E2 Internationally to many countries around the world.
This is 7-element NPN Darlington Pair 500 mA 60 V HFE:1000 16-Pin SOP manufactured by ROHM. The manufacturer part number is BA12003BF-E2. The product has a maximum 500 ma continuous collector current . It features up to 1000 of minimum DC current gain. The transistor is a npn type. The given dimensions of the product include 10 x 4.4 x 1.5mm. The product is available in surface mount configuration. Provides up to 620 mw maximum power dissipation. It has a maximum operating temperature of +85 °c. Whereas features a 60 v of collector emitter voltage (max). In addition, the height is 1.5mm. Furthermore, the product is 4.4mm wide. Its accurate length is 10mm. The package is a sort of sop. It consists of 7 elements per chip. Whereas, the minimum operating temperature of the product is -40 °c. The product has a maximum 1.6 v collector emitter saturation voltage . The product is available in array 7 configuration. With 1.35ma of base current . It contains 16 pins. The product offers common emitter transistor configuration.
