This is Programmable Timer Single 16-Pin PDIP manufactured by Texas Instruments. The manufacturer part number is CD4536BEE4. On the other hand, it is featured with 4.2ma of max. low level output current. It includes a/an programmable type timer . The given dimensions of the product include 19.3 x 6.35 x 4.57mm. The product is available in through hole configuration. It provides up to 8000 ns@ 5 v maximum propagation delay time. It has a maximum 0.1ma quiescent current . While its minimum operating supply voltage is 3 v. In addition, the height is 4.57mm. Moreover, it has 1 internal timers included . Furthermore, the product is 6.35mm wide. Its accurate length is 19.3mm. The package is a sort of pdip. Whereas, the minimum operating temperature of the product is -55 °c. It has 18 v maximum operating supply voltage. It has a maximum operating temperature of +125 °c. It contains 16 pins. While a -4.2ma of maximum high level output current. It is assigned with possible HTSUS value of 8542.39.0001. The product is rohs3 compliant. The product has -55°c ~ 125°c (ta) operating temperature range. Moreover, the product comes in 16-dip (0.300", 7.62mm). It comes in programmable timer configuration. In addition, it is reach unaffected. The current - supply of a bespoke product is 100 µa. The typical count of the product is 2 ~ 2²4. It is shipped in tube package . Its typical moisture sensitivity level is not applicable. It has a long 6 weeks standard lead time. 16-pdip is the supplier device package value. Supplied with 5mhz of frequency. It has optimum voltage supply of 3v ~ 18v. The product is designated with the ear99 code number.
Mult Dev Wafer Fab Site 22/Dec/2023(PCN Assembly/Origin)
CD4536B(Datasheets)
