Outlet Thread Standard:
ISO 7.1
Inlet Connection Type:
Threaded
Flow Factor Kv:
213L/min
Outlet Port Size:
Rp 1-1/4
Application:
Oil, Inert Gas, Air, Water
Outlet Connection Type:
Threaded
Inlet Port Gender:
Female
Inlet Port Size:
1-1/4 in
Servo Assist:
No
Product Type:
Solenoid Valve
Maximum Operating Temperature:
85°C
Outlet Port Gender:
Female
Hazardous Area Certification:
CSA, NEMA, ATEX Directive 2014/34/EU, UL
Number of Ports:
2
Body Material:
Brass
Standards/Approvals:
UL, EN 60529 (IP65), IEC 335, ISO 4400 / EN 175301-803, NEMA, Pressure Equipment Directive 2014/68/EU, form A, ATEX Directive 2014/34/EU, CSA
Default Valve Position:
NC
Series:
210
Orifice Diameter:
28mm
Inlet Thread Standard:
ISO 7.1
Minimum Operating Temperature:
-20°C
Supply Voltage:
48 V
