Minimum Operating Temperature:
0 °C, -10 °C, -30°C
Default Valve Position:
NC
Maximum Working Pressure:
10 bar
Series:
221
Connection Size:
3/4in
Operating Temperature Range:
0 → +120 Epoxy Coil (FKM) °C, 0 → +90 Polyamide Coil (FKM) °C, -10 → +80 (NBR) °C, -30 → +100 Epoxy Coil (EPDM) °C, -30 → +90 Polyamide Coil (EPDM) °C
Servo Assist:
Yes
Body Material:
Brass, Nickel Plated Brass, Stainless Steel
Maximum Opening Time:
4s
Orifice Diameter:
20mm
Number of Ports:
2
Connection:
3/4 in G Female
Thread Standard or Connection Type:
G
Supply Voltage:
110 V ac
Connection Gender:
Female
Suitable Applications:
Gas, Air, Vacuum Applications
Operation:
Pilot
Maximum Operating Temperature:
+100 °C, +120 °C, +80 °C, +90°C
Type:
2/2
Maximum Closing Time:
4s
