FET Feature:
-
HTSUS:
8541.29.0095
RoHS Status:
ROHS3 Compliant
Operating Temperature:
-55°C ~ 150°C (TJ)
Package / Case:
TO-247-3
Rds On (Max) @ Id, Vgs:
45mOhm @ 28A, 10V
Gate Charge (Qg) (Max) @ Vgs:
80 nC @ 10 V
Vgs(th) (Max) @ Id:
4.2V @ 250µA
FET Type:
N-Channel
Drive Voltage (Max Rds On, Min Rds On):
10V
Drain to Source Voltage (Vdss):
650 V
Vgs (Max):
±30V
Moisture Sensitivity Level (MSL):
3 (168 Hours)
Power Dissipation (Max):
312W (Tc)
standardLeadTime:
20 Weeks
Input Capacitance (Ciss) (Max) @ Vds:
4610 pF @ 400 V
Mounting Type:
Through Hole
Series:
-
Supplier Device Package:
TO-247 Long Leads
Packaging:
Tube
Current - Continuous Drain (Id) @ 25°C:
54A (Tc)
Technology:
MOSFET (Metal Oxide)
ECCN:
EAR99
Automotive Standard:
No
Maximum Power Dissipation Pd:
312W
Maximum Drain Source Voltage Vds:
650V
Channel Mode:
Enhancement
Typical Gate Charge Qg @ Vgs:
8nC
Series:
MDmesh M9
Maximum Gate Source Voltage Vgs:
±30 V
Forward Voltage Vf:
1.5V
Channel Type:
Type N
Width:
15.90 mm
Length:
20.10mm
Package Type:
TO-247
Minimum Operating Temperature:
-55°C
Maximum Drain Source Resistance Rds:
45mΩ
Standards/Approvals:
No
Maximum Continuous Drain Current Id:
54A
Product Type:
MOSFET
Maximum Operating Temperature:
150°C
Pin Count:
3
Mount Type:
Through Hole
