RS Pro DPDT PCB Mount Non-Latching Relay, 24V Coil, 3 A Subminiature DIP Relay
Product Information
Dimensions:
20 x 10.6 x 10.2mm
Electrical Life:
1000000 Cycles
Application:
General Purpose
Terminal Type:
Through Hole
Coil Resistance:
2800Ω
Life:
1000000 (Mechanical) Operations, 50000 (Electrical) Operations
Standards Met:
CQC 13002095174, cULus E133481, RoHS Compliant
Coil Power:
200mW
Maximum Switching Voltage DC:
220V
Maximum Switching Power DC:
90 W
Isolation Coil To Contact:
1.5kV rms
Maximum Operating Temperature:
+85°C
Switching Current:
3A
Maximum Switching Current AC:
3 A
Coil Voltage:
24V dc
Operating Temperature Range:
-40 → +85°C
Latching:
No
Contact Configuration:
DPDT
Depth:
10.1mm
Relay Switching Classification:
Subminiature DIP Relay
Features:
Wash Tight, Creepage Distance Of 10 mm, 5 mm Pinning
Mounting Type:
PCB Mount
Series:
G5V
Length:
20.5mm
Height:
10.6mm
Maximum Switching Current DC:
3 A
Maximum Switching Voltage AC:
250V
Minimum Operating Temperature:
-40°C
Maximum Switching Power AC:
125VA
Number of Poles:
2
Contact Material:
Silver
