Infineon EB 2ED2410 3D 1BCSP MOSFET Gate Driver for Gate Driver, Power MOSFET for 2ED2410-EM 24 V Evaluation Motherboard

The Infineon EB2ED24103D1BCSPTOBO1 is a robust expansion board designed for the 2ED2410‑EM 24 V evaluation motherboard, providing UK engineers a practical solution for power MOSFET gate driver testing. Equipped with two 60 V OptiMOS™ 5 power MOSFETs in a back-to-back common-source layout and a 0.5 mΩ shunt resistor, it efficiently supports 12 V and 24 V automotive-style board nets. This compact expansion module delivers up to 20 A continuously (30 A for 10 minutes), streamlining evaluation setups across power control, energy, and motor drive systems.

Key Reasons to Buy the Infineon Expansion Board

The EB2ED24103D1BCSPTOBO1 enables the precise, safe evaluation of Infineon’s Power MOSFETs within an integrated ecosystem. Its back-to-back MOSFET configuration ensures robust reverse current protection and accurate current sensing, while the embedded pre-charge path eases integration with capacitive loads. Designed for seamless compatibility with the 2ED2410‑EM evaluation motherboard, it accelerates UK prototype development in automotive, industrial, and energy applications, enabling fast, reliable insights into MOSFET performance.

Product Key Features and Benefits

• Back‑to‑back MOSFETs offer reliable reverse protection and safe switching.
• Pre‑charge path supports testing with high-capacitance loads smoothly.
• 0.5 mΩ shunt resistor delivers accurate current measurement and diagnostics.
• Integrated NTC temperature sensor enables real-time thermal monitoring.
• High-current capability 20 A continuous, 30 A for 10 minutes, ideal for intensive testing.

Wide Application Range

• Automotive power distribution unit prototyping and evaluation
• Industrial motor control and switching validation
• Energy storage and pre-charge circuits testing
• Educational and development bench for power electronics training
• In-house evaluation testing lab setups in UK engineering teams

For more information please check the datasheets.
