Diodes Inc 2N7002T-7-F N-channel MOSFET, 115 mA, 60 V, 3-Pin SOT-523

2N7002T-7-F Diodes Inc N-channel MOSFET, 115 mA, 60 V, 3-Pin SOT-523
2N7002T-7-F
2N7002T-7-F Diodes Inc N-channel MOSFET, 115 mA, 60 V, 3-Pin SOT-523
DiodesZetex

Product Information

Automotive Standard:
AEC-Q101
Maximum Power Dissipation Pd:
150mW
Product Type:
MOSFET
Maximum Drain Source Voltage Vds:
60V
Channel Mode:
Enhancement
Maximum Gate Source Voltage Vgs:
20 V
Series:
2N7002
Forward Voltage Vf:
1.4V
Height:
0.8mm
Width:
0.85 mm
Length:
1.7mm
Package Type:
SC-89
Minimum Operating Temperature:
-55°C
Maximum Drain Source Resistance Rds:
13.5Ω
Standards/Approvals:
No
Maximum Continuous Drain Current Id:
115mA
Channel Type:
Type N
Maximum Operating Temperature:
150°C
Pin Count:
3
Mount Type:
Surface
RoHs Compliant
Checking for live stock

This is Diodes Inc N-channel MOSFET 115 mA 60 V 3-Pin SOT-523 manufactured by DiodesZetex. The manufacturer part number is 2N7002T-7-F. The product complies with automotive standard - aec-q101. mosfet is a versatile product designed to provide user-defined applications. The product carries enhancement channel mode. The product 2n7002, is a highly preferred choice for users. In addition, the height is 0.8mm. Furthermore, the product is 0.85 mm wide. Its accurate length is 1.7mm. The package is a sort of sc-89. Whereas, the minimum operating temperature of the product is -55°c. The product is available in [Cannel Type] channel. It has a maximum operating temperature of 150°c. It contains 3 pins. It has a surface type mount .

pdf icon
2N7002T N-CHANNEL ENHANCEMENT MODE FIELD EFFECT TRANSISTOR Data Sheet(Technical Reference)
pdf icon
ESD Control Selection Guide V1(Technical Reference)
