ON Semi TIP147TTU Dual PNP Darlington Pair, -10 A 100 V HFE:500, 3-Pin TO-220

TIP147TTU ON Semi Dual PNP Darlington Pair, -10 A 100 V HFE:500, 3-Pin TO-220
TIP147TTU
TIP147TTU
ET13946726
ET13946726
Darlington Pairs
Darlington Pairs
Fairchild Semiconductor

Product Information

Minimum DC Current Gain:
500
Transistor Type:
PNP
Dimensions:
10.67 x 4.83 x 16.51mm
Mounting Type:
Through Hole
Maximum Power Dissipation:
80 W
Maximum Continuous Collector Current:
-10 A
Maximum Collector Base Voltage:
-100 V
Maximum Collector Emitter Voltage:
100 V
Maximum Base Emitter Saturation Voltage:
-3.5 V
Maximum Collector Cut-off Current:
-1mA
Height:
16.51mm
Width:
4.83mm
Length:
10.67mm
Package Type:
TO-220
Number of Elements per Chip:
2
Maximum Collector Emitter Saturation Voltage:
-2 V
Maximum Emitter Base Voltage:
-5 V
Maximum Operating Temperature:
+150 °C
Pin Count:
3
Transistor Configuration:
Single
RoHs Compliant
Checking for live stock

This is ON Semi Dual PNP Darlington Pair -10 A 100 V HFE:500 3-Pin TO-220 manufactured by Fairchild Semiconductor. The manufacturer part number is TIP147TTU. It features up to 500 of minimum DC current gain. The transistor is a pnp type. The given dimensions of the product include 10.67 x 4.83 x 16.51mm. The product is available in through hole configuration. Provides up to 80 w maximum power dissipation. The product has a maximum -10 a continuous collector current . Additionally, it has -100 v maximum collector base voltage. Whereas features a 100 v of collector emitter voltage (max). In addition, the product has a maximum -3.5 v base emitter saturation voltage . It has a maximum -1ma collector cut-off current . In addition, the height is 16.51mm. Furthermore, the product is 4.83mm wide. Its accurate length is 10.67mm. The package is a sort of to-220. It consists of 2 elements per chip. The product has a maximum -2 v collector emitter saturation voltage . It features a -5 v of maximum emitter base voltage. It has a maximum operating temperature of +150 °c. It contains 3 pins. The product offers single transistor configuration.

pdf icon
TIP145T/146T/147T, PNP Epitaxial Silicon Darlington Transistor Data Sheet(Technical Reference)
pdf icon
ESD Control Selection Guide V1(Technical Reference)

Reviews

  • Be the first to review.

FAQs

Yes. You can also search TIP147TTU on website for other similar products.
We accept all major payment methods for all products including ET13946726. Please check your shopping cart at the time of order.
You can order Fairchild Semiconductor brand products with TIP147TTU directly through our website or call us at +44 (0) 3303 800 157 or email our support team at sales@enrgtech.co.uk.
Yes. Our products in Darlington Pairs category are shipped in lowest possible time.
You will get a confirmation email regarding your order of ON Semi TIP147TTU Dual PNP Darlington Pair, -10 A 100 V HFE:500, 3-Pin TO-220. You can also check on our website or by contacting our customer support team for further order details on ON Semi TIP147TTU Dual PNP Darlington Pair, -10 A 100 V HFE:500, 3-Pin TO-220.
We use our internationally recognized delivery partners UPS/DHL. Collection of ET13946726 can also be arranged for the customer by international shipments through contacting our customer support team. Additionally, you can also search "Fairchild Semiconductor" products on our website by using Enrgtech's Unique Manufacturing Part Number ET13946726.
Yes. We ship TIP147TTU Internationally to many countries around the world.
