Vishay IHLP Series Type 6767 Shielded Wire-wound SMD Inductor with a Metal Composite Core, 330 nH ±20% Wire-Wound

Enrgtech Part No: ET16722499
|
Manufacturer Part No:
IHLP6767GZERR33M01
|
Manufacturer: Vishay

IHLP6767GZERR33M01 Vishay IHLP Series Type 6767 Shielded Wire-wound SMD Inductor with a Metal Composite Core, 330 nH ±20% Wire-Wound

Product Information

Maximum DC Resistance:

790µΩ

Inductor Construction:

Wire-Wound

Dimensions:

17.15 x 17.15 x 7mm

Shielded:

Yes

Series:

IHLP-6767GZ-01

Length:

17.15mm

Height:

7mm

Maximum DC Current:

65A

Depth:

17.15mm

Core Material:

Metal Composite

Inductance:

330 nH

Maximum Self Resonant Frequency:

2MHz

Checking for live stock

This is IHLP Series Type 6767 Shielded Wire-wound SMD Inductor with a Metal Composite Core 330 nH ±20% Wire-Wound manufactured by Vishay. The manufacturer part number is IHLP6767GZERR33M01. It allows up to 790µω maximum DC resistance. The inductor is designed as wire-wound inductor. The given dimensions of the product include 17.15 x 17.15 x 7mm. Shielding Options yes. The product ihlp-6767gz-01, is a highly preferred choice for users. Its accurate length is 17.15mm. In addition, the height is 7mm. While it carries 65a of maximum DC current. The product comes in 17.15mm depth. The core is manufactured from highly durable and reliable metal composite materials. The product has a 330 nh inductance value. It provides 2mhz of maximum self-resonant frequency. It has a maximum operating temperature of +125°c. It features ±20% of tolerance value. Whereas, the minimum operating temperature of the product is -55°c. Concerning its package and casing, it is 6767.
