Wurth WE-MAPI Series Type 2510 Wire-wound SMD Inductor with a Composite Iron Powder Core, 820 nH ±30% Moulded 2.6A Idc

Enrgtech Part No: ET14016725
|
Manufacturer Part No:
744383230082
|
Manufacturer: Wurth Elektronik

744383230082 Wurth WE-MAPI Series Type 2510 Wire-wound SMD Inductor with a Composite Iron Powder Core, 820 nH ±30% Moulded 2.6A Idc

Product Information

Maximum DC Resistance:

69mΩ

Inductor Construction:

Moulded

Dimensions:

2.5 x 2 x 1mm

Maximum DC Current:

2.6A

Series:

WE-MAPI

Length:

2.5mm

Height:

1mm

Depth:

2mm

Core Material:

Composite Iron Powder

Inductance:

820 nH

Maximum Self Resonant Frequency:

105MHz

Maximum Operating Temperature:

+125°C

Checking for live stock

This is Wurth WE-MAPI Series Type 2510 Wire-wound SMD Inductor with a Composite Iron Powder Core 820 nH ±30% Moulded 2.6A Idc manufactured by Wurth Elektronik. The manufacturer part number is 744383230082. It allows up to 69mω maximum DC resistance. The inductor is designed as moulded inductor. The given dimensions of the product include 2.5 x 2 x 1mm. While it carries 2.6a of maximum DC current. The product we-mapi, is a highly preferred choice for users. Its accurate length is 2.5mm. In addition, the height is 1mm. The product comes in 2mm depth. The core is manufactured from highly durable and reliable composite iron powder materials. The product has a 820 nh inductance value. It provides 105mhz of maximum self-resonant frequency. It has a maximum operating temperature of +125°c. It features ±30% of tolerance value. Whereas, the minimum operating temperature of the product is -40°c. Concerning its package and casing, it is 2510.

Ideal Power Inductors for Energy Efficient Applications - ANP031 Application Note(Technical Reference)

Accurate Inductor Loss Determination - Application Note(Technical Reference)

744383230082 Inductor SMD WE-MAPI Metal Alloy Data Sheet(Technical Reference)

Voids in Bottom Termination Components (BTC) - ANP036 Application Note(Technical Reference)

Application Note - The Sham of the High Rated Current(Technical Reference)

Your Rating

Reviews

Be the first to review.

FAQs

Yes. You can also search 744383230082 on website for other similar products.

We accept all major payment methods for all products including ET14016725. Please check your shopping cart at the time of order.

You can order Wurth Elektronik brand products with 744383230082 directly through our website or call us at +44 (0) 3303 800 157 or email our support team at sales@enrgtech.co.uk.

Yes. Our products in Wire-Wound Surface Mount Inductors category are shipped in lowest possible time.

You will get a confirmation email regarding your order of Wurth WE-MAPI Series Type 2510 Wire-wound SMD Inductor with a Composite Iron Powder Core, 820 nH ±30% Moulded 2.6A Idc. You can also check on our website or by contacting our customer support team for further order details on Wurth WE-MAPI Series Type 2510 Wire-wound SMD Inductor with a Composite Iron Powder Core, 820 nH ±30% Moulded 2.6A Idc.

We use our internationally recognized delivery partners UPS/DHL. Collection of ET14016725 can also be arranged for the customer by international shipments through contacting our customer support team. Additionally, you can also search "Wurth Elektronik" products on our website by using Enrgtech's Unique Manufacturing Part Number ET14016725.

Yes. We ship 744383230082 Internationally to many countries around the world.
