Analog Devices REF01CSZ-REEL7, Fixed Series Voltage Reference 10V, ±1.0 % 8-Pin, SOIC
Product Information
Load Regulation:
180 ppm/mA
Dimensions:
5 x 4 x 1.5mm
Mounting Type:
Surface Mount
Maximum Operating Temperature:
+85 °C
Line Regulation:
180 ppm/V
Maximum Input Voltage:
36 V
Height:
1.5mm
Width:
4mm
Length:
5mm
Initial Accuracy:
±1.0 %
Package Type:
SOIC
Maximum Output Voltage:
10.1 V
Minimum Operating Temperature:
-40 °C
Minimum Output Voltage:
9.9 V
Nominal Voltage:
10V
Reference Type:
Fixed
Maximum Output Current:
10mA
Pin Count:
8
Topology:
Series
Checking for live stock
FAQs
Yes. You can also search REF01CSZ-REEL7 on website for other similar products.
We accept all major payment methods for all products including ET14102531. Please check your shopping cart at the time of order.
You can order Analog Devices brand products with REF01CSZ-REEL7 directly through our website or call us at +44 (0) 3303 800 157 or email our support team at sales@enrgtech.co.uk.
Yes. Our products in Voltage References category are shipped in lowest possible time.
You will get a confirmation email regarding your order of Analog Devices REF01CSZ-REEL7, Fixed Series Voltage Reference 10V, ±1.0 % 8-Pin, SOIC. You can also check on our website or by contacting our customer support team for further order details on Analog Devices REF01CSZ-REEL7, Fixed Series Voltage Reference 10V, ±1.0 % 8-Pin, SOIC.
We use our internationally recognized delivery partners UPS/DHL. Collection of ET14102531 can also be arranged for the customer by international shipments through contacting our customer support team. Additionally, you can also search "Analog Devices" products on our website by using Enrgtech's Unique Manufacturing Part Number ET14102531.
Yes. We ship REF01CSZ-REEL7 Internationally to many countries around the world.
This is Fixed Series Voltage Reference 10V ±1.0 % 8-Pin SOIC manufactured by Analog Devices. The manufacturer part number is REF01CSZ-REEL7. Load Regulation - 180 ppm/ma. The given dimensions of the product include 5 x 4 x 1.5mm. The product is available in surface mount configuration. It has a maximum operating temperature of +85 °c. Has a line regulation of 180 ppm/v. 36 v is the maximum voltage of the bespoke product. In addition, the height is 1.5mm. Furthermore, the product is 4mm wide. Its accurate length is 5mm. Its initial accuracy is approximately ±1.0 % . The package is a sort of soic. Its output voltage (maximum) includes 10.1 v. Whereas, the minimum operating temperature of the product is -40 °c. The product features 9.9 v minimum output voltage. The nominal voltage of the product is 10v. The product has a reference of fixed type. Featuring 10ma of maximum output current. It contains 8 pins. Topology includes series.
