Dimensions:
14 x 9 x 5mm
Electrical Life:
100000 Operations
Terminal Type:
Through Hole
Coil Resistance:
2800Ω
Life:
1 x 10^8 cycles
Coil Power:
140mW
Maximum Switching Voltage DC:
110V
Maximum Switching Power DC:
30 W
Isolation Coil To Contact:
1.5kV rms
Maximum Operating Temperature:
+70°C
Switching Current:
2A
Maximum Switching Current AC:
0.5 A
Coil Voltage:
24V dc
Operating Temperature Range:
-40 → +70°C
Latching:
No
Contact Configuration:
DPDT
Depth:
9mm
Relay Switching Classification:
Subminiature Signal Relay
Features:
Offers Excellent Board Space Savings, Low Power Consumption, Single Or Double Coil Winding Type Available
Mounting Type:
PCB Mount
Series:
HFD31
Length:
14.5mm
Height:
5.4mm
Maximum Switching Current DC:
2 A
Maximum Switching Voltage AC:
125V
Minimum Operating Temperature:
-40°C
Maximum Switching Power AC:
62.5VA
Number of Poles:
2
Contact Material:
Gold Plated
This is 24 Colt Coil DPDT Contacts Fully Seale manufactured by Hongfa Europe GMBH. The manufacturer part number is HFD31/24-S. The given dimensions of the product include 14 x 9 x 5mm. The product offers long-lasting services of 100000 operations. The terminal is a through hole type. It holds up to 2800ω coil resistance. It is capable of doing 1 x 10^8 cycles in a lifetime . Robust coil power of 140mw. While it carries 110v of maximum DC switching voltage. It bears a maximum 30 w of DC switching power. The product has 1.5kv rms isolation coil to contact. It has a maximum operating temperature of +70°c. It is integrated with 2a switching current. It has a maximum 0.5 a switching current AC . The coil voltage of the product is 24v dc. The product has -40 → +70°c of operating temperature range. Latching Options - no. The contact is equipped with dpdt configuration. The product comes in 9mm depth. It has a subminiature signal relay switching relay configuration . The splendid features of the product include offers excellent board space savings, low power consumption, single or double coil winding type available. The product is available in pcb mount configuration. The product hfd31, is a highly preferred choice for users. Its accurate length is 14.5mm. In addition, the height is 5.4mm. It has a minimum 2 a DC switching current . It has a maximum AC switching voltage of 125v. Whereas, the minimum operating temperature of the product is -40°c. It also features an AC switching power of 62.5va. It has equipped with 2 poles. The product is made from sturdy gold plated materials.
