Dimensions:
14 x 9 x 5mm
Electrical Life:
100000 Operations
Terminal Type:
PCB Pin
Coil Resistance:
1028Ω
Life:
1 x 10^8 cycles
Coil Power:
140mW
Maximum Switching Voltage DC:
110V
Maximum Switching Power DC:
30 W
Isolation Coil To Contact:
1.5kV ac
Maximum Operating Temperature:
+70°C
Switching Current:
2A
Maximum Switching Current AC:
0.5 A
Coil Voltage:
12V dc
Operating Temperature Range:
-40 → +70°C
Latching:
No
Contact Configuration:
DPDT
Depth:
9mm
Relay Switching Classification:
Subminiature Signal Relay
Features:
Offers Excellent Board Space Savings, Low Power Consumption, Single Or Double Coil Winding Type Available
Mounting Type:
PCB Mount
Series:
HFD31
Length:
14mm
Height:
5.4mm
Maximum Switching Current DC:
2 A
Maximum Switching Voltage AC:
125V
Minimum Operating Temperature:
-40°C
Maximum Switching Power AC:
62.5VA
Number of Poles:
2
Contact Material:
Gold Plated
