Dimensions:
15 x 8.2 x 7.4mm
Coil Voltage:
5V dc
Application:
Domestic Appliances, General Purpose, Medical Equipment, Safety
Terminal Type:
PCB Pin
Coil Resistance:
178Ω
Life:
1 x 10^5 (Electrical) Operations, 10^8 (Mechanical) Operations
Coil Power:
140mW
Maximum Switching Voltage DC:
220V
Maximum Switching Power DC:
60 W
Isolation Coil To Contact:
750V
Maximum Operating Temperature:
+85°C
Switching Current:
2A
Operating Temperature Range:
-40 → +85°C
Latching:
No
Contact Configuration:
DPDT
Depth:
7.4mm
Features:
Outstanding Surge Resistance, Sealed Construction Allows Automatic Washing,
Mounting Type:
Surface Mount
Series:
G6K
Length:
15mm
Height:
8.2mm
Maximum Switching Current DC:
2 A
Minimum Operating Temperature:
-40°C
Number of Poles:
2
Contact Material:
Gold Plated
