Analog Devices AD8502ARJZ-R2, Low Power, Op Amp, RRIO, 7kHz, 1.8 → 5.5 V, 8-Pin SOT-23

AD8502ARJZ-R2 Analog Devices , Low Power, Op Amp, RRIO, 7kHz, 1.8 → 5.5 V, 8-Pin SOT-23
Analog Devices

Product Information

Typical Dual Supply Voltage:
±0.9 → ±2.75V
Typical Input Voltage Noise Density:
190nV/√Hz
Typical Gain Bandwidth Product:
7kHz
Dimensions:
3 x 1.7 x 1.3mm
Mounting Type:
Surface Mount
Typical Slew Rate:
0.004V/µs
Power Supply Type:
Dual, Single
Number of Channels per Chip:
2
Rail to Rail:
Rail to Rail Input/Output
Maximum Operating Frequency:
1 kHz
Height:
1.3mm
Typical Single Supply Voltage:
1.8 → 5.5 V
Width:
1.7mm
Length:
3mm
Package Type:
SOT-23
Minimum Operating Temperature:
-40 °C
Amplifier Type:
Low Power
Typical Voltage Gain:
120 dB
Maximum Operating Temperature:
+125 °C
Pin Count:
8
RoHs Compliant
Checking for live stock

This is Low Power Op Amp RRIO 7kHz 1.8 → 5.5 V 8-Pin SOT-23 manufactured by Analog Devices. The manufacturer part number is AD8502ARJZ-R2. While ±0.9 → ±2.75v is the typical dual supply voltage. Featuring a 190nv/√hz of typical input voltage noise density. Features 7khz typical gain bandwidth. The given dimensions of the product include 3 x 1.7 x 1.3mm. The product is available in surface mount configuration. Furthermore, it has a typical 0.004v/µs of slew rate. It is a type of dual, single power supply. It comprises 2 channels per chip. Rail to rail options include rail to rail input/output. It carries 1 khz of maximum operating frequency. In addition, the height is 1.3mm. It has a typical single supply voltage of 1.8 → 5.5 v. Furthermore, the product is 1.7mm wide. Its accurate length is 3mm. The package is a sort of sot-23. Whereas, the minimum operating temperature of the product is -40 °c. It is a sort of a low power amplifier. Furthermore, its typical voltage gain includes 120 db. It has a maximum operating temperature of +125 °c. It contains 8 pins.

pdf icon
AD8502/AD8504, 1 μA Micropower CMOS Operational Amplifiers(Technical Reference)
pdf icon
ESD Control Selection Guide V1(Technical Reference)
