Dimensions:
15.7 x 11 x 12mm
Electrical Life:
100000 cycles
Application:
Signal
Coil Resistance:
120 Ω
Life:
100000 (Electrical) cycles, 10000000 (Mechanical) cycles
Standards Met:
CQC, CULus, RoHS Compliant
Coil Power:
200mW
Maximum Switching Voltage DC:
30V dc
Maximum Switching Power DC:
30 W
Isolation Coil To Contact:
1kV ac
Maximum Operating Temperature:
+70°C
Terminal Type:
Through Hole
Coil Voltage:
5 V dc
Operating Temperature Range:
-25 → +70°C
Switching Current:
3 A
Contact Configuration:
SPDT
Depth:
11mm
Relay Switching Classification:
Subminiature Signal Relay
Special Features:
Extremely Low Cost
Mounting Type:
PCB Mount
Length:
15.7mm
Height:
12mm
Maximum Switching Voltage AC:
240V ac
Minimum Operating Temperature:
-25°C
Maximum Switching Power AC:
600 VA
Number of Poles:
1
Contact Material:
Silver Alloy
