Maximum AC Current Measurement:
10A ac
Power Source:
Mains
DC Voltage Accuracy:
0.02 %
Width:
302 mm
AC Voltage Resolution:
10μV
True RMS:
Yes
Resistance Measurement Accuracy:
±0.1% + 3 Digits
Maximum DC Current Measurement:
10A
Model Number:
IDM8341
AC Current Accuracy:
±0.5 % rdg + 20 Digits
Maximum Frequency:
1MHz
AC Voltage Accuracy:
0.35 %
DC Current Resolution:
10nA dc
DC Current Accuracy:
0.02 %
Maximum Operating Temperature:
50°C
DC Voltage Resolution:
10 μV
Maximum AC Voltage Measurement:
750V ac
AC Current Resolution:
0.01μA ac
Safety Category Level:
CAT IV, CAT II, CAT III
Length:
265mm
Maximum Resistance Measurement:
50mΩ
Standards/Approvals:
No
Maximum DC Voltage Measurement:
1000V
Display Type:
Digital
Product Type:
Multimeter
Weight:
2.9kg
Series:
IDM-8341/8342
Safety Category Voltage:
600V
Multimeter Type:
Bench
Height:
107mm
Minimum Operating Temperature:
0°C
Resistance Resolution:
10mΩ
Functions Measured:
Frequency, Capacitance, RMS, AC Current, Conductance, Resistance, DC Voltage, DC Current, Diode, AC Voltage, Temperature
