Width:
14 mm
Height:
1.7mm
Automotive Standard:
No
Number of Timers:
5
RAM Size:
448kB
Data Bus Width:
16bit
Instruction Set Architecture:
ARM
Program Memory Type:
RAM
Minimum Supply Voltage:
1.7V
Package Type:
LFBGA
Maximum Clock Frequency:
800MHz
Product Type:
Microcontroller
Maximum Operating Temperature:
125°C
Device Core:
ARM Cortex A7
Length:
14mm
Standards/Approvals:
RoHS
Interface Type:
IIS, IIC, Ethernet, CAN, USB, SPI, SDM, SAI
Pin Count:
289
Mount Type:
Surface
Number of Programmable I/Os:
135
Series:
STM32MP1
Maximum Supply Voltage:
3.6V
ADCs:
2 x 12 Bit
Minimum Operating Temperature:
-40°C
USB:
USB 2.0 (2)
HTSUS:
8542.31.0001
RoHS Status:
ROHS3 Compliant
Number of Cores/Bus Width:
1 Core, 32-Bit
Supplier Device Package:
289-LFBGA (14x14)
Additional Interfaces:
CANbus, GPIO, I2C, I2S, IrDA, MMC/SD/SDIO, SAI, SPDIF, SPI, UART/USART
Operating Temperature:
-40°C ~ 105°C (TJ)
Package / Case:
289-LFBGA
Co-Processors/DSP:
Multimedia; NEON™ SIMD
edacadModel:
STM32MP135FAE7 Models
edacadModelUrl:
/en/models/17775601
RAM Controllers:
DDR3, DDR3L, LPDDR2, LPDDR3
Manufacturer:
STMicroelectronics
Security Features:
AES, ARM TZ, Boot Security, Cryptography, Secure Debug, SHA-1/2, Tamper Detection, TRNG, Volatile key Storage
Moisture Sensitivity Level (MSL):
3 (168 Hours)
Ethernet:
10/100/1000Mbps (2)
standardLeadTime:
10 Weeks
Graphics Acceleration:
Yes
Display & Interface Controllers:
LCD
Mounting Type:
Surface Mount
Series:
STM32MP1
Voltage - I/O:
1.8V, 2.5V, 3.3V
Packaging:
Tray
SATA:
-
Core Processor:
ARM® Cortex®-A7
Speed:
1GHz
ECCN:
5A992C
