Dimensions:
24 x 10 x 18.8mm
Electrical Life:
20000 operations
Application:
Home Appliances, Industrial Equipment, Lighting Control Equipment, Security Equipment, Smart Meters, Various Power Supplies
Coil Resistance:
90 Ω
Life:
Minimum of 1000000 (Mechanical) operations, Minimum of 20000 (Electrical) operations
Standards Met:
CSA, CUL, CULus, IEC 60335-1, PTI 325V, TV-8, UL, VDE
Coil Power:
400mW
Isolation Coil To Contact:
5000Vrms
Maximum Operating Temperature:
+70°C
Terminal Type:
PCB Pin
Coil Voltage:
6 V dc
Operating Temperature Range:
-40 → +70°C
Switching Current:
16 A
Contact Configuration:
SPNO
Depth:
10mm
Relay Switching Classification:
Latching Relay
Features:
Small Polarised Power Relays, 1 Form A 16 A
Mounting Type:
PCB Mount
Length:
24mm
Height:
18.8mm
Maximum Switching Voltage AC:
277V
Minimum Operating Temperature:
-40°C
Maximum Switching Power AC:
4.432 kVA
Number of Poles:
1
Contact Material:
Silver Alloy
This is SPNO PCB Mount Latching Relay 16 A 6V dc manufactured by Panasonic. The manufacturer part number is ADW1206HTW. The given dimensions of the product include 24 x 10 x 18.8mm. The product offers long-lasting services of 20000 operations. Applications Information involves home appliances, industrial equipment, lighting control equipment, security equipment, smart meters, various power supplies. It holds up to 90 ω coil resistance. It is capable of doing minimum of 1000000 (mechanical) operations, minimum of 20000 (electrical) operations in a lifetime . The product complies with all safety standards, such as csa, cul, culus, iec 60335-1, pti 325v, tv-8, ul, vde. Robust coil power of 400mw. The product has 5000vrms isolation coil to contact. It has a maximum operating temperature of +70°c. The terminal is a pcb pin type. The coil voltage of the product is 6 v dc. The product has -40 → +70°c of operating temperature range. It is integrated with 16 a switching current. The contact is equipped with spno configuration. The product comes in 10mm depth. It has a latching relay switching relay configuration . The splendid features of the product include small polarised power relays, 1 form a 16 a. The product is available in pcb mount configuration. Its accurate length is 24mm. In addition, the height is 18.8mm. It has a maximum AC switching voltage of 277v. Whereas, the minimum operating temperature of the product is -40°c. It also features an AC switching power of 4.432 kva. It has equipped with 1 poles. The product is made from sturdy silver alloy materials.
