Hirose FH26 0.3mm Pitch 39 Way Right Angle SMT Female FPC Connector, ZIF Bottom Contact

FH26W-39S-0-3SHW-99- Hirose FH26 0.3mm Pitch 39 Way Right Angle SMT Female FPC Connector, ZIF Bottom Contact
FH26W-39S-0.3SHW(99)
Hirose

Product Information

Current Rating:
200mA
Termination Type:
ZIF Bottom Contact
Mounting Type:
Surface Mount
Voltage Rating:
30 V ac
Gender:
Female
Body Orientation:
Right Angle
Pitch:
0.3mm
Termination Method:
Solder
Housing Material:
Liquid Crystal Polymer, Polyamide
Number of Rows:
2
Contact Plating:
Gold
Series:
FH26
Number of Contacts:
39
Maximum Operating Temperature:
+85°C
Minimum Operating Temperature:
-55°C
Contact Material:
Phosphor Bronze
RoHs Compliant
Checking for live stock

This is FH26 0.3mm Pitch 39 Way Right Angle SMT Female FPC Connector ZIF Bottom Contact manufactured by Hirose. The manufacturer part number is FH26W-39S-0.3SHW(99). The product has a current rating of 200ma. The product is designed with a zif bottom contact termination. The product is available in surface mount configuration. Moreover, the product has a nominal 30 v ac voltage rating. In addition, female is the available "Gender" of the product. It has right angle body orientation. Moreover, the product is 0.3mm. It allows solder termination method. The product also features robust liquid crystal polymer, polyamide housing material. It comes in 2 of rows. The high-quality gold is used as contact plating material. The product fh26, is a highly preferred choice for users. The product contains 39 contacts. It has a maximum operating temperature of +85°c. Whereas, the minimum operating temperature of the product is -55°c. The product is made from sturdy phosphor bronze materials.

pdf icon
FFC Connector 0.3mm pitch FH 26 Series Data Sheet(Technical Reference)
