Maximum Temperature:
+70°C
AC or DC Output Voltage:
dc
Minimum Temperature:
-20°C
AC or DC Input Voltage:
ac
Width:
45mm
MTBF:
1500000h
Electrical Phase:
1
Type:
Switched Mode
Load Regulation:
1%
Standards Met:
CE
Efficiency:
89%
Input Voltage:
100 → 240V ac
Output Voltage Adjustment Range:
24V
Ripple And Noise:
75mV
Depth:
100mm
Special Features:
Overvoltage and Short Circuit Protection
Better World Verification:
Green Premium
Better World Product:
Yes
Mounting Type:
DIN Rail Mount
Output Current:
3.8A
Series:
ABLS1A
Height:
75mm
Output Voltage:
24V dc
Power Rating:
91.2W
HTSUS:
8504.40.9510
RoHS Status:
ROHS3 Compliant
Power (Watts):
91W
Current - Output (Max):
3.8A
Approval Agency:
CB, CE, CSA, CuL, EAC, EN, IEC, KC, NEC Class 2, UL
Input Type:
AC
Applications:
ITE (Commercial)
Voltage - Output 4:
-
Voltage - Output 5:
-
Voltage - Output 6:
-
Voltage - Output 1:
24V
Voltage - Output 2:
-
Voltage - Output 3:
-
Efficiency:
89%
Manufacturer:
Schneider Electric
DC Voltage - Input (Max):
-
DC Voltage - Input (Min):
-
Minimum Load Required:
-
Size / Dimension:
3.94" L x 1.77" W x 2.95" H (100.0mm x 45.0mm x 75.0mm)
standardLeadTime:
8 Weeks
Voltage - Isolation:
3 kV
AC Voltage - Input:
100 ~ 240 VAC
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Features:
IP20, Universal Input
Series:
-
Operating Temperature:
-20°C ~ 70°C (With Derating)
Packaging:
Box
Standard Number:
60950-1; 62368-1
Number of Outputs:
1
ECCN:
EAR99
