Maximum Temperature:
+70°C
AC or DC Output Voltage:
dc
Dimensions:
90 x 72 x 110mm
Minimum Temperature:
-25°C
AC or DC Input Voltage:
ac, dc
Width:
72mm
MTBF:
>1300000h
Electrical Phase:
1
Load Regulation:
0.5%
Standards Met:
CB Scheme, cCSAus, CE, cULus, cUS Recognised, EN 50022-35X15/7.5, EN 50178, EN 55022, EN 60204, EN 61000-6-2, EN 61000-6-3, EN 61204-3, EN 61558-2-16, EN 61558-2-8, IEC 61000-3-2, IEC/EN 60335-1, IEC/EN 60529, IEC/EN 60950-1, IEC/EN 61000-4-11, IEC/EN 61000-4-2, IEC/EN 61000-4-3, IEC/EN 61000-4-4, IEC/EN 61000-4-5, IEC/EN 61000-4-6, IEC/EN 61000-4-8, IEC/EN 62477, IP20, NEC, SI, UL 1310, UL 508, UL 60950-1, UL 94 V-0
Efficiency:
87%
Input Voltage:
85 → 264 V ac / 90 → 375V dc
Number of Outputs:
1
Output Voltage Adjustment Range:
12 → 15V
Ripple And Noise:
100mV Pk-Pk
Depth:
110mm
Special Features:
Adjustable Output Voltage, Low Output Ripples & Noise, Power Good Signal
Mounting Type:
DIN Rail Mount
Output Current:
8A
Series:
TPC
Height:
90mm
Output Voltage:
12V dc
Power Rating:
96W
