Maximum Temperature:
+70°C
AC or DC Output Voltage:
dc
Dimensions:
124.2 x 36 x 118.6mm
Minimum Temperature:
-40°C
AC or DC Input Voltage:
ac
Width:
36mm
MTBF:
>1450000h
Electrical Phase:
1
Type:
Switched Mode
Load Regulation:
0.5%
Standards Met:
CB Scheme, cCSAus, CE, cULus, EN 50022-35X15/7.5, EN 50178, EN 55022, EN 60204, EN 61000-6-2, EN 61000-6-3, EN 61204-3, EN 61558-2-16, EN 61558-2-8, IEC 61000-3-2, IEC/EN 60335-1, IEC/EN 60529, IEC/EN 60950-1, IEC/EN 61000-4-11, IEC/EN 61000-4-2, IEC/EN 61000-4-3, IEC/EN 61000-4-4, IEC/EN 61000-4-5, IEC/EN 61000-4-6, IEC/EN 61000-4-8, IEC/EN 62477, IP20, NEC, SI, UL 1310, UL 508, UL 60950-1
Efficiency:
94%
Input Voltage:
85 → 264V ac
Number of Outputs:
1
Output Voltage Adjustment Range:
23.5 → 28V
Ripple And Noise:
100mV Pk-Pk
Depth:
118.6mm
Special Features:
Active Power Factor, Adjustable Output Voltage, Alternative Side-Mounting for Flat Panels, Back Power Immunity
Mounting Type:
DIN Rail Mount
Output Current:
5A
Series:
TIB
Height:
124.2mm
Output Voltage:
24V dc
Power Rating:
120W
