Maximum Temperature:
+70°C
AC or DC Output Voltage:
dc
Minimum Temperature:
-25°C
AC or DC Input Voltage:
ac, dc
Width:
90mm
MTBF:
>500000h
Electrical Phase:
1
Type:
Power
Standards Met:
61000-4-4, 61000-4-5, 61000-4-6, CE Certified, cULus Listed, cULus Recognized, EAC, EN 50178/VDE 0160, EN 55022, EN 60204, EN 60950, EN 61000-3-2, EN 61000-4-11, EN 61000-4-2, EN 61000-4-3, EN 61000-4-8, IEC 1709, IEC 60068-2-27, IEC 60068-2-6, IEC 61204, IEC 61558-2-16, TUV, VDE 0100-410/DIN57100-410, VDE 0106-101
Efficiency:
92%
Input Voltage:
85 → 277V ac
Number of Outputs:
1
Output Voltage Adjustment Range:
29.5V
Ripple And Noise:
<50mV
Depth:
150mm
Special Features:
Durable, High Performance
Mounting Type:
DIN Rail Mount
Output Current:
20A
Series:
PRO MAX
Height:
130mm
Output Voltage:
24V dc
Power Rating:
480W
Manufacturer Standard Lead Time:
16 Weeks
Number of Outputs:
1
Detailed Description:
Enclosed AC DC Converter 1 Output 24V 20A 85 ~ 277 VAC, 80 ~ 370 VDC Input
Voltage - Isolation:
4kV
Features:
Adjustable Output, IP20
Mounting Type:
DIN Rail
Applications:
ITE (Commercial)
Series:
PRO MAX (480W)
Voltage - Output 1:
24V
Size / Dimension:
5.91" L x 3.54" W x 5.12" H (150.0mm x 90.0mm x 130.0mm)
Efficiency:
92%
Power (Watts):
480W
Current - Output (Max):
20A
Approvals:
CE, cULus, cuRus, EAC, TUV
Voltage - Input:
85 ~ 277 VAC, 80 ~ 370 VDC
Operating Temperature:
-25°C ~ 70°C
Type:
Enclosed
Manufacturer:
Weidmuller
