Number of Outputs:
1
Ripple And Noise:
<50mV
Output Current:
20A
Standards Met:
61000-4-4, 61000-4-5, 61000-4-6, CE Certified, cULus Listed, EAC, EN 50178/VDE 0160, EN 55022, EN 60204, EN 60950, EN 61000-3-2, EN 61000-4-11, EN 61000-4-2, EN 61000-4-3, EN 61000-4-8, IEC 1709, IEC 60068-2-27, IEC 60068-2-6, IEC 61558-2-16, VDE 0100-410/DIN57100-410, VDE 0106-101
Mounting Type:
DIN Rail Mount
Maximum Temperature:
+70°C
Series:
PRO ECO
Electrical Phase:
1
Special Features:
Compact Size, Easy to Maintain, Flexible, High Efficiency
AC or DC Input Voltage:
ac, dc
Height:
125mm
Width:
100mm
Depth:
120mm
MTBF:
>500000h
Output Voltage:
24V dc
Minimum Temperature:
-25°C
AC or DC Output Voltage:
dc
Power Rating:
480W
Input Voltage:
85 → 264V ac
Manufacturer Standard Lead Time:
16 Weeks
Number of Outputs:
1
Detailed Description:
Enclosed AC DC Converter 1 Output 24V 20A 85 ~ 264 VAC Input
Voltage - Isolation:
3kV
Features:
Adjustable Output, DC Input Capable, IP20, Load Sharing, PFC, Universal Input
Mounting Type:
DIN Rail
Applications:
ITE (Commercial)
Series:
PRO ECO (480W)
Voltage - Output 1:
24V
Size / Dimension:
4.72" L x 3.94" W x 4.92" H (120.0mm x 100.0mm x 125.0mm)
Efficiency:
91%
Power (Watts):
480W
Current - Output (Max):
20A
Approvals:
CE, cULus
Voltage - Input:
85 ~ 264 VAC
Operating Temperature:
-25°C ~ 70°C (With Derating)
Type:
Enclosed
Manufacturer:
Weidmuller
