Fairchild Semiconductor MM74HC245ASJ, Dual, Transceiver, 16-Bit Non-Inverting CMOS, 2 → 6 V, 8-Pin SOP

MM74HC245ASJ Fairchild Semiconductor , Dual, Transceiver, 16-Bit Non-Inverting CMOS, 2 → 6 V, 8-Pin SOP
Fairchild Semiconductor

Product Information

Polarity:
Non-Inverting
Dimensions:
12.6 x 5.3 x 1.8mm
Minimum Operating Supply Voltage:
2 V
Logic Family:
74HC
Width:
5.3mm
Input Level:
CMOS
Maximum Low Level Output Current:
7.8mA
Maximum High Level Output Current:
7.8mA
Maximum Propagation Delay Time @ Maximum CL:
17 ns @ 45 pF
Number of Channels per Chip:
16
Package Type:
SOP
Number of Elements per Chip:
2
Maximum Operating Temperature:
+85 °C
Output Level:
CMOS
Length:
12.6mm
Pin Count:
8
Maximum Operating Supply Voltage:
6 V
Mounting Type:
Surface Mount
Logic Function:
Transceiver
Height:
1.8mm
Minimum Operating Temperature:
-40 °C
Propagation Delay Test Condition:
45pF
RoHs Compliant
Checking for live stock

This is Dual Transceiver 16-Bit Non-Inverting CMOS 2 → 6 V 8-Pin SOP manufactured by Fairchild Semiconductor. The manufacturer part number is MM74HC245ASJ. While providing non-inverting polarity. The given dimensions of the product include 12.6 x 5.3 x 1.8mm. While its minimum operating supply voltage is 2 v. The logic family is 74hc. Furthermore, the product is 5.3mm wide. Additionally, it has a standard cmos input level . On the other hand, it is featured with 7.8ma of max. low level output current. While a 7.8ma of maximum high level output current. It provides up to 17 ns @ 45 pf maximum propagation delay time. It comprises 16 channels per chip. The package is a sort of sop. It consists of 2 elements per chip. It has a maximum operating temperature of +85 °c. Its output level is cmos . Its accurate length is 12.6mm. It contains 8 pins. It has 6 v maximum operating supply voltage. The product is available in surface mount configuration. The primary function of logic includes transceiver. In addition, the height is 1.8mm. Whereas, the minimum operating temperature of the product is -40 °c. Features 45pf of propagation delay test condition.

pdf icon
MM74HC245A, Octal 3-State Transceiver Data Sheet(Technical Reference)
