Diodes Inc ZXTN25060BZTA NPN Transistor, 5 A, 60 V, 3-Pin SOT-89
Product Information
Dimensions:
4.6 x 2.6 x 1.6mm
Maximum Collector Emitter Saturation Voltage:
305 mV
Width:
2.6mm
Transistor Configuration:
Single
Maximum Operating Frequency:
185 MHz
Package Type:
SOT-89
Number of Elements per Chip:
1
Maximum Operating Temperature:
+150 °C
Transistor Type:
NPN
Maximum Collector Base Voltage:
150 V
Maximum Base Emitter Saturation Voltage:
1100 mV
Maximum Emitter Base Voltage:
7 V
Length:
4.6mm
Maximum DC Collector Current:
5 A
Pin Count:
3
Minimum DC Current Gain:
300
Mounting Type:
Surface Mount
Maximum Power Dissipation:
1.1 W
Maximum Collector Emitter Voltage:
60 V
Height:
1.6mm
Minimum Operating Temperature:
-55 °C
Checking for live stock
FAQs
Yes. You can also search ZXTN25060BZTA on website for other similar products.
We accept all major payment methods for all products including ET16759938. Please check your shopping cart at the time of order.
You can order DiodesZetex brand products with ZXTN25060BZTA directly through our website or call us at +44 (0) 3303 800 157 or email our support team at sales@enrgtech.co.uk.
Yes. Our products in Bipolar Transistors category are shipped in lowest possible time.
You will get a confirmation email regarding your order of Diodes Inc ZXTN25060BZTA NPN Transistor, 5 A, 60 V, 3-Pin SOT-89. You can also check on our website or by contacting our customer support team for further order details on Diodes Inc ZXTN25060BZTA NPN Transistor, 5 A, 60 V, 3-Pin SOT-89.
We use our internationally recognized delivery partners UPS/DHL. Collection of ET16759938 can also be arranged for the customer by international shipments through contacting our customer support team. Additionally, you can also search "DiodesZetex" products on our website by using Enrgtech's Unique Manufacturing Part Number ET16759938.
Yes. We ship ZXTN25060BZTA Internationally to many countries around the world.
This is Diodes Inc NPN Transistor 5 A 60 V 3-Pin SOT-89 manufactured by DiodesZetex. The manufacturer part number is ZXTN25060BZTA. The given dimensions of the product include 4.6 x 2.6 x 1.6mm. The product has a maximum 305 mv collector emitter saturation voltage . Furthermore, the product is 2.6mm wide. The product offers single transistor configuration. It carries 185 mhz of maximum operating frequency. The package is a sort of sot-89. It consists of 1 elements per chip. It has a maximum operating temperature of +150 °c. The transistor is a npn type. Additionally, it has 150 v maximum collector base voltage. In addition, the product has a maximum 1100 mv base emitter saturation voltage . It features a 7 v of maximum emitter base voltage. Its accurate length is 4.6mm. Moreover, it has a maximum DC collector current of 5 a. It contains 3 pins. It features up to 300 of minimum DC current gain. The product is available in surface mount configuration. Provides up to 1.1 w maximum power dissipation. Whereas features a 60 v of collector emitter voltage (max). In addition, the height is 1.6mm. Whereas, the minimum operating temperature of the product is -55 °c.
