Diodes Inc ZTX696B NPN Transistor, 500 mA, 180 V, 3-Pin TO-92
Product Information
Minimum DC Current Gain:
500
Transistor Type:
NPN
Dimensions:
4.77 x 2.41 x 4.01mm
Mounting Type:
Through Hole
Maximum Power Dissipation:
1 W
Maximum Collector Base Voltage:
300 V
Maximum Collector Emitter Voltage:
180 V
Maximum Operating Frequency:
50 MHz
Maximum Emitter Base Voltage:
5 V
Package Type:
TO-92
Number of Elements per Chip:
1
Maximum DC Collector Current:
500 mA
Maximum Operating Temperature:
+200 °C
Pin Count:
3
Transistor Configuration:
Single
Checking for live stock
FAQs
Yes. You can also search ZTX696B on website for other similar products.
We accept all major payment methods for all products including ET13844613. Please check your shopping cart at the time of order.
You can order DiodesZetex brand products with ZTX696B directly through our website or call us at +44 (0) 3303 800 157 or email our support team at sales@enrgtech.co.uk.
Yes. Our products in Bipolar Transistors category are shipped in lowest possible time.
You will get a confirmation email regarding your order of Diodes Inc ZTX696B NPN Transistor, 500 mA, 180 V, 3-Pin TO-92. You can also check on our website or by contacting our customer support team for further order details on Diodes Inc ZTX696B NPN Transistor, 500 mA, 180 V, 3-Pin TO-92.
We use our internationally recognized delivery partners UPS/DHL. Collection of ET13844613 can also be arranged for the customer by international shipments through contacting our customer support team. Additionally, you can also search "DiodesZetex" products on our website by using Enrgtech's Unique Manufacturing Part Number ET13844613.
Yes. We ship ZTX696B Internationally to many countries around the world.
This is Diodes Inc NPN Transistor 500 mA 180 V 3-Pin TO-92 manufactured by DiodesZetex. The manufacturer part number is ZTX696B. It features up to 500 of minimum DC current gain. The transistor is a npn type. The given dimensions of the product include 4.77 x 2.41 x 4.01mm. The product is available in through hole configuration. Provides up to 1 w maximum power dissipation. Additionally, it has 300 v maximum collector base voltage. Whereas features a 180 v of collector emitter voltage (max). It carries 50 mhz of maximum operating frequency. It features a 5 v of maximum emitter base voltage. The package is a sort of to-92. It consists of 1 elements per chip. Moreover, it has a maximum DC collector current of 500 ma. It has a maximum operating temperature of +200 °c. It contains 3 pins. The product offers single transistor configuration.
