Festo EV-40-5, Clamping Module

The Festo EV-40-5 clamping module mechanically holds linear motion components in place. It is typically installed on guide units, slides, or actuator systems to safely secure loads when air pressure is removed. This module belongs to the EV series and is designed for industrial automation setups that require controlled stopping and holding. It works as a safety and positioning component rather than a drive element. Once engaged, it locks the moving axis in place to prevent unwanted movement.

Unique Features and Benefits of the Festo EV-40-5 Clamping Module, EV Series

The EV-40-5 uses a spring-loaded clamping mechanism that grips the guide when activated. This design allows the module to hold the load securely even during pressure loss or emergency stop conditions.

• Mechanical clamping for secure holding.
• Spring-based locking principle.
• Designed for linear guides and slides.
• Suitable for systems where load stability is critical.

Clamping Module for Controlled Linear Holding

The module is built for continuous use in automated machinery. Its compact construction allows it to fit into tight machine layouts without interfering with other components. It is typically mounted directly onto compatible guide systems, keeping installation predictable and straightforward. Once installed, the clamping action operates consistently without requiring constant adjustment, ensuring reliable machine operation over time.

Broad Range Application

It is mainly applied in situations where movement must stop immediately and remain fixed until released.

• Linear guide and slide assemblies
• Pick-and-place systems
• Assembly and handling machines
• Vertical axes where load drop prevention is required

For more information please check the datasheets.
