Bourns PVG5A Series 11-Turn SMD Trimmer Resistor with J-Hook Terminations, 10kΩ ±10% 1/4W ±150ppm/°C Top Adjust
Product Information
Shaft Diameter:
1.5 mm
Orientation:
Top Adjust
Mounting Type:
Surface Mount
Series:
PVG5
Termination Style:
J-Hook
Number of Turns:
12
Temperature Coefficient:
±150ppm/°C
Length:
4.8mm
Minimum Operating Temperature:
-55°C
Power Rating:
0.25W
Maximum Resistance:
10kΩ
Tolerance:
±10%
Maximum Operating Temperature:
+125°C
Technical Documents
Checking for live stock
More Information
11-Turn 250mW 5mm Top Adjust PVG5A Series
11 turn high resolution trimmers permitting accurate adjustment
Compatible with the VPS wave soldering standard and passing through the ultra-sounds tank
Clutch mechanism prevents excessive wiper rotation
Applications: s...
11-Turn 250mW 5mm Top Adjust PVG5A Series
11 turn high resolution trimmers permitting accurate adjustment
Compatible with the VPS wave soldering standard and passing through the ultra-sounds tank
Clutch mechanism prevents excessive wiper rotation
Applications: sensors, industrial machines, CPU's, measuring instruments
Power
250mW
Resistance Tolerance
±10%
Voltage Maximum
300Vdc
Temperature Coefficient
200ppm/°C (R200Ω)
End Resistance
Operating Torque
17.6mNm
Soldering temperature
260°C 3 sec (Max.)
Operating Temperature
-55°C → +125°C
Contact Resistance Variation
>3% (Maximum)
Linear Or Logarithmic
Linear
Dimensions (mm)
5 x 4.8 x 3.5
Multi-Turn Surface Mount Trimmers
