Name: VS-16TTS12-M3, Vishay
Brand: Vishay
SKU: ET16724242
Price: 2.78 GBP
Availability: InStock

VS-16TTS12-M3 Vishay, , Thyristor, 1200V 10A, 60mA 3-Pin, TO-220AC

(0)

Product Information

Repetitive Peak Forward Blocking Voltage:

1200V

Repetitive Peak Reverse Voltage:

1200V

Peak On-State Voltage:

1.4V

Dimensions:

10.54 x 4.57 x 8.76mm

Mounting Type:

Through Hole

Surge Current Rating:

200A

Rated Average On-State Current:

10A

Repetitive Peak Off-State Current:

0.5mA

Package Type:

TO-220AC

Minimum Operating Temperature:

-40 °C

Maximum Holding Current:

100mA

Maximum Gate Trigger Current:

60mA

Checking for live stock

The VS-16TTS12-M3 from Vishay is a high-voltage, phase-controlled silicon-controlled rectifier (SCR) designed for demanding switching, control, and power conversion tasks. Housed in a TO-220AB package, it supports an average on-state current of 10 A and repetitive voltage blocking up to 1.2 kV. Engineered for thermal resilience and robust switching, this through-hole thyristor is designed to fit into various applications, including motor drives, UPS circuits, welders, and crowbar protection systems.

What Makes the Vishay VS-16TTS12-M3 Thyristor Stand Out?

This through-hole thyristor stands out due to its high blocking voltage of 1.2 kV, its ability to handle an average current of 10 A (16 A RMS), and its reliable operation up to a junction temperature of 125 °C, all backed by Vishay’s quality and JEDEC/JESD qualification.

Functional Highlights of the VS-16TTS12-M3

Repetitive off-state voltage (VDRM / VRRM): 1.2 kV
Average on-state current (IT(AV)): 10 A
RMS on-state current: 16 A
Non-repetitive surge current capability (10 ms pulse): ~200 A
Gate trigger current (IGT): up to 60 mA
Low on-state voltage drop (VTM ~1.4 V at 10 A)
Package: TO-220AB, through-hole mounting
Operating junction temperature up to 125 °C.

VS-16TTS..PbF Series, VS-16TTS..-M3 Series, Thyristor High Voltage, Phase Control SCR, 16A(Technical Reference)
