This is Dual Thyristor Module IGBT 135A 1600V 7-Pin INT-A-PAK manufactured by Vishay. The manufacturer part number is VSKT136/16PBF. Moreover, it has a repetitive peak forward blocking voltage about 1200v . It has about 1600v repetitive reverse voltage . It has a peak on-state voltage about 1.57v . The given dimensions of the product include 94 x 35 x 30mm. The product is available in panel mount configuration. It has about 3.36ka surge current rating . Moreover, it has about 135a rated average on-state current . In addition, the height is 30mm. Furthermore, the product is 35mm wide. Its accurate length is 94mm. Its repetitive peak off-state current is approximately 50ma . The package is a sort of int-a-pak. Whereas, the minimum operating temperature of the product is -40 °c. The product has a maximum 200ma holding current . In addition, the product has a maximum 270ma gate trigger current . In addition, the product has a/an igbt type thyristor . It has a maximum operating temperature of +125 °c. It contains 7 pins. Moreover, it has a maximum 4v gate trigger voltage .
