Manufacturer Standard Lead Time:
6 Weeks
Style:
Board to Cable/Wire
Detailed Description:
Connector Header Through Hole, Right Angle 7 position 0.100" (2.54mm)
Operating Temperature:
-40°C ~ 105°C
Contact Finish Thickness - Post:
150.0µin (3.81µm)
Number of Positions:
7
Contact Length - Post:
0.130" (3.30mm)
Insulation Height:
0.215" (5.45mm)
Insulation Color:
Black
Shrouding:
Shrouded - 4 Wall
Applications:
Automotive, General Purpose, Industrial, Medical
Number of Rows:
1
Material Flammability Rating:
UL94 V-0
Contact Shape:
Square
Manufacturer:
Molex
Voltage Rating:
250V
Connector Type:
Header
Contact Length - Mating:
0.240" (6.10mm)
Number of Positions Loaded:
All
Contact Finish Thickness - Mating:
150.0µin (3.81µm)
Fastening Type:
Latch Holder
Termination:
Solder
Pitch - Mating:
0.100" (2.54mm)
Features:
Board Guide
Mounting Type:
Through Hole, Right Angle
Series:
SL 70555
Packaging:
Tube
Contact Finish - Mating:
Tin
Contact Type:
Male Pin
Contact Finish - Post:
Tin
Insulation Material:
Polyester, Glass Filled
Contact Material:
Phosphor Bronze
Contact Material:
Brass and Phosphor Bronze
Number of Contacts:
7
Orientation:
Right Angle
Housing Material:
High Temperature Thermoplastic
Shrouded/Unshrouded:
Shrouded
Series:
70555
Current:
3A
Number of Rows:
1
Standards/Approvals:
RoHS Compliant
Voltage:
250V
Contact Plating:
Tin
Pitch:
2.54mm
Termination Type:
Solder
Product Type:
Header
Maximum Operating Temperature:
105°C
Minimum Operating Temperature:
-40°C
Mount Type:
Through Hole
