Push Button Colour:
Yellow
IP Rating:
IP69K, IP67, IP66, IP69
Series:
XB4B
Push Button Marking:
Unbeschriftet
Push Button Shape:
Round
Hazardous Area Certification:
No
Standards/Approvals:
UL, CSA, IEC 60947-5-5, CSA C22.2 No. 14, NEMA 13, DNV, IEC 60947-5-1, UL 508, IK06 (IEC 50102), JIS C8201-1, JIS C8201-5-1, NEMA 4X, LROS, IEC 60947-5-4, BV, IEC 60947-1
Push Button Style:
Standard Front Element Type
Cutout Diameter:
22.5mm
Product Type:
Push Button Head
Push Button Actuation:
Spring Return
Push Button Diameter:
22.5mm
HTSUS:
8536.50.9035
RoHS Status:
ROHS3 Compliant
Electrical Life:
1,000,000 Cycles
Termination Style:
Screw Terminal
Voltage Rating - DC:
125 V
Operating Temperature:
-40°C ~ 70°C
Panel Cutout Dimensions:
Circular - 22.00mm Dia
Mechanical Life:
10,000,000 Cycles
Type:
Standard
Color - Actuator/Cap:
Yellow
Voltage Rating - AC:
120 V
Illumination Type, Color:
-
Switch Function:
On-Off, Off-On
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Circuit:
DPST-NO/NC
standardLeadTime:
5 Weeks
Current Rating (Amps):
6A (AC), 550mA (DC)
Ingress Protection:
IP66/IP67/IP69/IP69K - Dust Tight, Water Resistant, Waterproof
Features:
-
Mounting Type:
Panel Mount, Front
Series:
Harmony XB4
Packaging:
Box
Actuator Type:
Round, Button, Flush
Illumination Voltage (Nominal):
-
ECCN:
EAR99
