Phoenix Contact 2967060
Product Information
Dimensions:
80 x 14 x 94mm
Coil Voltage:
24V dc
Turn On Time:
8ms
Turn Off Time:
10ms
Input Current:
18mA
Life:
3 x 10^7 Cycles
Switching Voltage:
250V ac/dc
Input Resistance:
1.3kΩ
Maximum Operating Temperature:
+60°C
Terminal Type:
Screw
Relay Type:
Solid State Relay
Operating Temperature Range:
-40 → +60°C
Contact Configuration:
DPDT
Depth:
14mm
Relay Switching Classification:
Miniature Relay
Special Features:
Degree of protection IP20
Mounting Type:
DIN Rail
Series:
PLC-RSC- 24DC/21-21
Input Voltage Range:
20.2 → 33.6V dc
Accessory Type:
Relay Module
Length:
80mm
Height:
94mm
Minimum Operating Temperature:
-40°C
Minimum Input Voltage:
20.2V
Number of Poles:
2
Maximum Input Voltage:
24V dc
Contact Material:
Silver Alloy
HTSUS:
8536.41.0020
RoHS Status:
ROHS3 Compliant
Coil Voltage:
24VDC
Termination Style:
Screw Terminal
REACH Status:
REACH Affected
Operating Temperature:
-40°C ~ 60°C
Coil Current:
18 mA
Coil Type:
Non Latching
Switching Voltage:
250VAC, 250VDC - Max
Seal Rating:
-
edacadModel:
2967060 Models
edacadModelUrl:
/en/models/349731
Must Operate Voltage:
-
Relay Type:
General Purpose
Package:
Bulk
Contact Form:
DPDT (2 Form C)
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Operate Time:
8 ms
Must Release Voltage:
-
standardLeadTime:
8 Weeks
Contact Rating (Current):
6 A
Features:
Lighted Indicator, Socket Included
Mounting Type:
DIN Rail
Series:
PLC-RSC
Release Time:
10 ms
Coil Insulation:
-
Contact Material:
Silver Nickel (AgNi)
Base Product Number:
29670
ECCN:
EAR99
Checking for live stock
FAQs
Yes. You can also search 2967060 on website for other similar products.
We accept all major payment methods for all products including ET11621932. Please check your shopping cart at the time of order.
You can order Phoenix Contact brand products with 2967060 directly through our website or call us at +44 (0) 3303 800 157 or email our support team at sales@enrgtech.co.uk.
Yes. Our products in Power Relays, Over 2 Amps category are shipped in lowest possible time.
You will get a confirmation email regarding your order of Phoenix Contact 2967060. You can also check on our website or by contacting our customer support team for further order details on Phoenix Contact 2967060.
We use our internationally recognized delivery partners UPS/DHL. Collection of ET11621932 can also be arranged for the customer by international shipments through contacting our customer support team. Additionally, you can also search "Phoenix Contact" products on our website by using Enrgtech's Unique Manufacturing Part Number ET11621932.
Yes. We ship 2967060 Internationally to many countries around the world.
This is manufactured by Phoenix Contact. The manufacturer part number is 2967060. The given dimensions of the product include 80 x 14 x 94mm. The coil voltage of the product is 24v dc. It has a 8ms turn On time. The given turn off time is 10ms. It has about 18ma input current . It is capable of doing 3 x 10^7 cycles in a lifetime . The product's switching voltage is 250v ac/dc. Moreover, it has approximately 1.3kω input resistance . It has a maximum operating temperature of +60°c. The terminal is a screw type. This is basically a solid state relay. The product has -40 → +60°c of operating temperature range. The contact is equipped with dpdt configuration. The product comes in 14mm depth. It has a miniature relay switching relay configuration . The product also provides special features, such as degree of protection ip20. The product is available in din rail configuration. The product plc-rsc- 24dc/21-21, is a highly preferred choice for users. It has 20.2 → 33.6v dc of input voltage range. It is a type of relay module accessory. Its accurate length is 80mm. In addition, the height is 94mm. Whereas, the minimum operating temperature of the product is -40°c. The product has 20.2v of minimum input voltage. It has equipped with 2 poles. 24v dc is the maximum voltage of the bespoke product. The product is made from sturdy silver alloy materials. It is assigned with possible HTSUS value of 8536.41.0020. The product is rohs3 compliant. The coil voltage of the product is 24vdc. Moreover, it has screw terminal terminal style. In addition, it is reach affected. The product has -40°c ~ 60°c operating temperature range. It has a coil current of 18 ma. The coil is a non latching type. The product's switching voltage is 250vac, 250vdc - max. This is basically a general purpose. It is shipped in bulk package . It also has a dpdt (2 form c) contact form. Its typical moisture sensitivity level is 1 (unlimited). The operating time of the product is 8 ms. It has a long 8 weeks standard lead time. It has a contact current rating of 6 a. The splendid features of the product include lighted indicator, socket included. The product plc-rsc, is a highly preferred choice for users. While 10 ms is its release time. The product is made from sturdy silver nickel (agni) materials. Moreover, it corresponds to 29670, a base product number of the product. The product is designated with the ear99 code number.
