Maximum Flow Rate:
210L/min
Number of Positions:
3
Maximum Operating Pressure:
1 Mpa
Valve Function:
3 Directional Flow
Product Type:
Pneumatic Solenoid Valve
Maximum Operating Temperature:
50°C
Electrical Connection Type:
2-Pin, Horizontal Connection, Plug, Plug Pattern H
Hazardous Area Certification:
No
Number of Ports:
5
Body Material:
Wrought Aluminium Alloy
Standards/Approvals:
VDMA24364 zone III, IP40, FN 942017-5 and EN 60068-2-27, RCM, Class 5 According to ISO 14644-1, FN 942017-4 and EN, RoHS, ISO 8573-1:2010 (7:4:4)
Actuation Type:
Electric
Seal Material:
Nitrile Rubber (NBR)
Solenoid Power Consumption:
0.8W
Mount Type:
Rail
Minimum Pilot Pressure:
0.3MPa
Width:
10.1 mm
Series:
VUVG
Port Type:
M5
Length:
86.5mm
Height:
32.5mm
Voltage:
24V
Minimum Operating Temperature:
-5°C
