Schneider Electric SPDT PCB Mount Non-Latching Relay, 120V ac Coil, 20 A
Product Information
Dimensions:
29.5 x 13 x 25.5mm
Coil Voltage:
120 V ac
Application:
Power
Coil Resistance:
5.6 kΩ
Life:
100000 (Electrical) Operations, 10000000 (Mechanical) Operations
Coil Power:
1.2W
Maximum Switching Voltage DC:
48V
Isolation Coil To Contact:
5kV ac
Maximum Operating Temperature:
+55°C
Terminal Type:
PCB Pin
Maximum Switching Current AC:
20 A
Operating Temperature Range:
-40 → +55°C
Contact Configuration:
SPDT
Depth:
13mm
Mounting Type:
PCB Mount
Length:
29.5mm
Height:
25.5mm
Maximum Switching Current DC:
20 A
Maximum Switching Voltage AC:
300V
Minimum Operating Temperature:
-40°C
Contact Material:
Silver Alloy
Checking for live stock
FAQs
Yes. You can also search 976XAX97H-120A on website for other similar products.
We accept all major payment methods for all products including ET14050579. Please check your shopping cart at the time of order.
You can order Schneider Electric brand products with 976XAX97H-120A directly through our website or call us at +44 (0) 3303 800 157 or email our support team at sales@enrgtech.co.uk.
Yes. Our products in Non-Latching Relays category are shipped in lowest possible time.
You will get a confirmation email regarding your order of Schneider Electric SPDT PCB Mount Non-Latching Relay, 120V ac Coil, 20 A. You can also check on our website or by contacting our customer support team for further order details on Schneider Electric SPDT PCB Mount Non-Latching Relay, 120V ac Coil, 20 A.
We use our internationally recognized delivery partners UPS/DHL. Collection of ET14050579 can also be arranged for the customer by international shipments through contacting our customer support team. Additionally, you can also search "Schneider Electric" products on our website by using Enrgtech's Unique Manufacturing Part Number ET14050579.
Yes. We ship 976XAX97H-120A Internationally to many countries around the world.
This is SPDT PCB Mount Non-Latching Relay 120V ac Coil 20 A manufactured by Schneider Electric. The manufacturer part number is 976XAX97H-120A. The given dimensions of the product include 29.5 x 13 x 25.5mm. The coil voltage of the product is 120 v ac. Applications Information involves power. It holds up to 5.6 kω coil resistance. It is capable of doing 100000 (electrical) operations, 10000000 (mechanical) operations in a lifetime . Robust coil power of 1.2w. While it carries 48v of maximum DC switching voltage. The product has 5kv ac isolation coil to contact. It has a maximum operating temperature of +55°c. The terminal is a pcb pin type. It has a maximum 20 a switching current AC . The product has -40 → +55°c of operating temperature range. The contact is equipped with spdt configuration. The product comes in 13mm depth. The product is available in pcb mount configuration. Its accurate length is 29.5mm. In addition, the height is 25.5mm. It has a minimum 20 a DC switching current . It has a maximum AC switching voltage of 300v. Whereas, the minimum operating temperature of the product is -40°c. The product is made from sturdy silver alloy materials.
