Maximum AC Current Measurement:
3mA ac
Power Source:
Lithium-ion Battery, USB
DC Voltage Accuracy:
0.2+20 % rdg. + d (300 V,1000 V), 0.15+10 % rdg. + d (300 mV,3 V,30 V)
Width:
105 mm
Battery Life:
20h
Other Measurement Range:
Inductance with COIL adapter: 10 μH to 50 mH, 10 μH to 5 H
True RMS:
Yes
Maximum DC Current Measurement:
3mA dc
Model Number:
M272S
AC Current Accuracy:
1.0+30 % rdg. + d
Maximum Frequency:
300kHz
AC Voltage Accuracy:
0.15+10 % rdg
Battery Type:
Lithium-Polymer, 3.7 V
DC Current Resolution:
1A
Maximum Operating Temperature:
50°C
Maximum AC Voltage Measurement:
1000V ac
Safety Category Level:
CAT IV, CAT III
Length:
235mm
Maximum Resistance Measurement:
3000mΩ
Standards/Approvals:
EN 610101, EN 610102033, EN 615574, EN 615572, EN 60529, EN 613261, EN 615571
Maximum DC Voltage Measurement:
1000V
Display Type:
Digital
Product Type:
Multimeter
Weight:
0.7kg
Safety Category Voltage:
1000V
Multimeter Type:
Handheld
Height:
56mm
Minimum Operating Temperature:
-10°C
Resistance Resolution:
1kΩ
Functions Measured:
DC Voltage, Inrush Current, Resistance, Diode, Temperature, AC Voltage, Frequency, AC Current, Continuity
