Toshiba TC4069UBF(EL,N,F), Hex, Inverting Inverter, 14-Pin SOP
Product Information
Maximum Low Level Output Current:
12mA
Maximum High Level Output Current:
-9mA
Dimensions:
10.8 x 5.3 x 1.5mm
Mounting Type:
Surface Mount
Maximum Propagation Delay Time @ Maximum CL:
110 ns @ 50 pF
Minimum Operating Supply Voltage:
3 V
Minimum Operating Temperature:
-40 °C
Logic Function:
Inverter
Propagation Delay Test Condition:
50pF
Output Type:
Inverting
Height:
1.5mm
Width:
5.3mm
Length:
10.8mm
Package Type:
SOP
Logic Family:
CMOS
Input Type:
CMOS
Maximum Operating Supply Voltage:
18 V
Maximum Operating Temperature:
+85 °C
Pin Count:
14
Number of Elements per Chip:
6
Checking for live stock
FAQs
Yes. You can also search TC4069UBF(EL,N,F) on website for other similar products.
We accept all major payment methods for all products including ET16797822. Please check your shopping cart at the time of order.
You can order Toshiba brand products with TC4069UBF(EL,N,F) directly through our website or call us at +44 (0) 3303 800 157 or email our support team at sales@enrgtech.co.uk.
Yes. Our products in Inverters ICs category are shipped in lowest possible time.
You will get a confirmation email regarding your order of Toshiba TC4069UBF(EL,N,F), Hex, Inverting Inverter, 14-Pin SOP. You can also check on our website or by contacting our customer support team for further order details on Toshiba TC4069UBF(EL,N,F), Hex, Inverting Inverter, 14-Pin SOP.
We use our internationally recognized delivery partners UPS/DHL. Collection of ET16797822 can also be arranged for the customer by international shipments through contacting our customer support team. Additionally, you can also search "Toshiba" products on our website by using Enrgtech's Unique Manufacturing Part Number ET16797822.
Yes. We ship TC4069UBF(EL,N,F) Internationally to many countries around the world.
This is Hex Inverting Inverter 14-Pin SOP manufactured by Toshiba. The manufacturer part number is TC4069UBF(EL,N,F). On the other hand, it is featured with 12ma of max. low level output current. While a -9ma of maximum high level output current. The given dimensions of the product include 10.8 x 5.3 x 1.5mm. The product is available in surface mount configuration. It provides up to 110 ns @ 50 pf maximum propagation delay time. While its minimum operating supply voltage is 3 v. Whereas, the minimum operating temperature of the product is -40 °c. The primary function of logic includes inverter. Features 50pf of propagation delay test condition. Furthermore, it has ainverting output. In addition, the height is 1.5mm. Furthermore, the product is 5.3mm wide. Its accurate length is 10.8mm. The package is a sort of sop. The logic family is cmos. It carries cmos input type. It has 18 v maximum operating supply voltage. It has a maximum operating temperature of +85 °c. It contains 14 pins. It consists of 6 elements per chip.
