Number of Levels:
1
Fused:
No
Termination Type:
Screw
Series:
UKH 95
Colour:
Grey
Minimum Operating Temperature:
-60°C
Minimum Wire Size AWG:
4 AWG
Terminal Block Current:
232A
Hazardous Area Certification:
IECEx, ATEX
Standards/Approvals:
CCA, cUL, DNV, EAC, EAC Ex, IEC 60947-7-1, IECEX, KEMA-KEUR, LR, PRS, RS, UL, CCC, CSA, ATEX
Voltage:
1 kV
Cable CSA:
25 to 95 mm²
Maximum Wire Size AWG:
0 AWG
Product Type:
Feed Through Terminal Block
Maximum Operating Temperature:
110°C
Sub Type:
High Current
HTSUS:
8536.69.8000
RoHS Status:
ROHS3 Compliant
Termination Style:
Screw
Material - Insulation:
Polyamide (PA), Nylon
Type:
Feed Through
Number of Positions:
2
Wire Gauge or Range - mm²:
25-95mm²
REACH Status:
REACH Unaffected
edacadModel:
3010013 Models
Material Flammability Rating:
UL94 V-0
edacadModelUrl:
/en/models/349862
Package:
Bulk
Stripping Length:
33mm
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Current - IEC:
232 A
Wire Gauge or Range - AWG:
4/0-2 AWG
Voltage - UL:
600V
standardLeadTime:
8 Weeks
Terminal - Width:
25.0mm
Disconnect Type:
-
Voltage - IEC:
1000V
Features:
-
Color:
Gray
Series:
CLIPLINE UKH
Fuse Type:
-
Current - UL:
230 A
Number of Levels:
1
ECCN:
EAR99
